Applicable fibers: SM MM DS NZ-DS EDF
Cladding diameter: 100 to 150um Coating diameter: 100 to 1000um
Fiber cleaved length: 8^ 22mm ( standard) Splicing mode: Auto & Manual Average splice loss: 0.02dB( SM) 0.01dB( MM) 0.04dB( DS) 0.04dB( NZDS) Return loss: e 60dB Environment conditions: -25 ^ 50 ( operation temperature) , 0 ^ 95% RH ( humidity) , 0 ^ 5000m ( altitude) Storage environment: -40 ^ + 80 ( temperature) , 0 ^ 95 RH ( humidity) Protection sleeve length: 20mm 40mm 60mm Tension test: 2.0N ( Standard) Language: English, Chinese, Korea, Russian, Spanish etc. Interface: RS232 interface & video output Power supply: AC adaptor 85 ^ 260V input voltage Internal battery 12V voltage, 10Ah, up to 200 times of continuous splices and heats DC adaptor 12V voltage optional multipurpose external battery Dimensions: 170 W × 140 H × 170( D) mm Weight: 3.3kg
